| Model |
YSL-K8 |
| Print Head |
KM 512 |
| Ink Drop |
|
|
42 pl |
|
|
| Number of Head |
8 |
| Number of Color |
4 |
| Print Head (firing) Frequency |
Maxium 8KHz |
| Print Resolution |
Real 360dpi * 720dpi |
| Print Hend Hight |
Adjustable |
1-10mm |
| Print Width |
3.2m |
| PRINT SPEED (240 dpi) |
2Pass |
60m2/hour
HIGH SPEED |
| 3Pass |
40m2/hour
HIGH SPEED |
| 4Pass |
30m2/hour
HIGH SPEED |
| Ink |
Type |
SOLVENT INK |
| Color |
C.M,Y,K |
| Media |
Type |
PVC FLEX, VINYL,ONE WAY VISION |
| Feed_ in System |
YES |
| Take_ up System |
YES |
| Image File Format |
PSD/DWG/HPG/HGL/PLT/PS/EPS/2PS/FJB/JPG/TIF/BMP |
| Print Workflow |
Print job from control panel/Direct print job from PC |
| Cleaning System |
AUTO CLEANING SYSTEM |
| Heanting System |
TWO SECTIONS |
| Drying System |
COLD WIND |
| Print Interface |
USB Interface |
| RIP Software |
TOPAZ Business Version(Multi Language Itergrated,English, Spnanish Etc.) |
| Workstation Conflguration |
Operation System |
WindowsXP Home, XP Professional |
| CPU |
Pentium4, ≥1500MHz |
| Memory |
2G |
| Free HD |
80G |
| Emvironment |
Humidity |
45-75%CH |
| Temperture |
20-27℃ |
| Packing size |
|
W*D*H(mm) |
|
| Gross Weigth |
|
|
|
| Note: The modification of the data & contents above will mot especially be notified |
